Harmony Series | 64,000 GRAINS Water Softener

I do not have the room to put an unit inside. Could this be installed outside? I have a well house already with room in it, could it possibly be added to it?

The Digital Control Valve on our Harmony Water Softener does need to be enclosed and protected from the elements. If you install the unit outside, it would need to be protected entirely in an enclosure to retain its warranty.

I would like to purchase this softener model with fine media where can I buy

We sell that system here through our store.

compression fittings for line going into salt tank

We no longer use the bulkhead fittings on standard brine tanks. Those can normally be removed and the line fed straight through.

Is the flow design co-current or counter-current? What is the brine consumption on regen?

Our systems employ the counter-flow method that pushes the water down into the resin for proper ion exchange. The 64,000-grain tanks consume between 8-11 lbs of salt during regeneration.

What is the service flow rate for this model?

The service flow rate for this model is 20gpm.

Can I install outdoors is it water proof

• An outdoor install is unfortunately not recommended as it voids the warranty. Due to the electrical control valve head, we would not be able to guarantee the best performance if the system is exposed to the elements. When exposed to the elements, there is also the chance for rust to occur, which can be a slow killer for the system.
• In rare instances, certain homes are plumed to have the inlet/outlet meet the water softener outside. If this is the case, we highly recommend building a small shed or enclosure around the system to keep it safe from the elements.

wat kind of salt should I use in my 64000 grains system

We tend to recommened the pellet shaped salt as it tends to dissolve more evenly than other shapes. However, the system will take any type of salt so long as the salt states that it is formulated for water softener use.

Can you tell me what if any the difference is between model HS-H64D and the model 64FM.

The 64FM includes a Fine Mesh Resin that also eliminates iron in the water on top of softening the water.

64000 grain is the max capacity of this system is the performing capacity is same? If not how much it is to be used for system capacity calculation.

You would normally use the following calculation to determine the best number of gallons to set for the system. By default the control head will start with just 1000 gallons.

https://aquasureusa.com/pages/aquasure-harmony-water-softener-support?q=calculator

How much water and salt is used for regeneration

Gallons Consumption Per Regeneration:

64 Grain  -  50-75 gallons

Salt Consumption per regeneration:

64 Grain   -  18-20 lbs of salt

What are the electrical requirements for this unit? Are there things other than salt that are routinely added or maintained?

What are the electrical requirements for this unit?

Class 2 Power Supply / AC Adapator

Input : 120 V ~ 60Hz

Output: 24V ~ 450mA

my water has tested at 19 - 21 grams hardness and 11 to 14 ppm iron. Can the HS64D handle the iron. what is the iron rating on this model.

Normally we would recommend the fine mesh version of the 64,000-grain system AS-HS64-FM. However, the AS-HS64-FM can only provide a maximum of 10 PPM of iron filtration/reduction and if your iron levels are between 11-14 PPM then they far exceed what the system can effectively filter. With that being said, we would recommend looking into a different system as non of our water softeners would be able to filter out such high iron levels. We hope this information helps.

Need to know how much space I would need for both the brine tank and the resin tank? We use a pelican salt free water softener which has been a way overpriced absolute joke! Pretty sure it does absolutely nothing. We have limited space where it’s at though and before I purchase I need to know if it will fit.

The AS-HS64D system require a floor space of 18" x 30" minimum to operate. the dimension of the system is 13" Dia. x 64" H for the resine tank and 16" W x 16" L x 35" H for the brine tank. Depending on how the line is connected, it might require more space to properly install the system.

Do you recommend a plumber?

To answer your question, plenty of people have installed our water softener systems themselves with no issues. However, if you are not as confident with plumbing work we generally recommend seeking out a professionally licensed plumber in your area and to shop around for the best qoute for install.

Is this product able to be installed outside?

Thanks for reaching out to Aquasure Support regarding your install question. We always recommended an inside install as we cannot guarantee great performance if it is installed outside amongst the elements, which can also lead to system damage. If you absolutely must install the system outside we recommend building a small shed or enclosure to ensure that the system is protected from the elements.

At the rated 20 gpm, what is the pressure drop?

The pressure drop should be minimal, but it is dependant upon the incoming water pressure of your home

Are your systems NSF44 rated?

No, they are not NSF44 rated

How much iron will the 48000 and the 64000 grain units remove?

The amount of iron removed from your water will actually depend upon which resin you choose.
Our systems come standard with a resin that can remove up to 2 parts per million (2ppm) of iron, whereas our upgraded Fine Mesh resin can remove up to 10 parts per million.

The system sizes tell you how many grains per gallon of hardness they are able to remove before needing to be regenerated: I.e. the 48,000 Grain Harmony removes 48,000 grains of hardness from your water before it needs to regenerate the resin beads so they can continue softening your water.

I hope this answers your questions. Please reach out to us via phone or email if you have any further questions or concerns.

Thank you!
